Nordson Asymtek X-1000 Series User Manual

Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 5-24 P/N 196515 (Revision A)
Exercise Sheet 5-4-4
Installing the Scale (Continued)
6. Install the Dispensing Calibration Module (See Diagram Sheet 5-4-2 on page 5-19).
Place the DCM on the Adjustment Bracket and install the three 4-mm socket
head cap screws and washers.
- Do not fully tighten the screws until leveling has been completed.
Connect the Needle Sensor Cable to the DCM.
Place the Breeze Shield into the Weigh Station hole in the DCM so it rests on the
Top Plate of the Balance Module.
Carefully install the Scale Pedestal by placing it straight down inside the Breeze
Shield.
Avoid putting pressure on the Scale Pedestal or damage to the sensitive
weighing mechanism will occur.
Install a clean plastic cup on the Scale Pedestal inside the Breeze Shield.
Install the Weigh Station Cover.
7. Reinstall the Dispensing Area Front Cover (See Diagram Sheet 5-4-1 on page 5-17).
Position the Cover on the brackets at the front of the dispensing chamber such
that the fasteners align with the holes.
Turn each of the six Phillips head fasteners 1/4-turn to secure the Cover to the
mounting brackets.
8. Install the new Scale Control Module in the Rear Cabinet (See Diagram Sheet 5-4-1
on page 5-17).
Place the Scale Control Module on the Cabinet floor and align the holes.
Install the two 4-mm socket head cap screws and washers. Torque the screws to
25 in-lbs (0.288 kg-m).
Connect the Scale Communication Cable, Scale Power Cable, and the Scale
Interconnect Cable to the Scale Control Module.
To prepare the new Scale for operation:
1. Level the Dispensing Calibration Module in relation to a sample workpiece. Refer to
Exercise Sheet 2-9-1 on page 2-81).
Leveling the Scale requires the dispensing system to be level.
2. Perform Valve Offset Routine in accordance with the FmNT User Guide.
3. Calibrate the Scale in accordance with “Scale Leveling and Calibration” as outlined in
Lesson 3.3 on page 3-11.
The FmNT software Setup and Configuring of the Scale is done at the Asymtek factory.
If the Scale is inadvertently disabled, contact Asymtek Technical Support on how to
proceed.
