Maintenance
3
ADJUST
2
SET NOZZLE MAP
Press the OK button.
4
>SET NOZZLE MAP
2
Lc
, ,
Press the Up and Down buttons to select the
color to be set and press the OK button.
This shows an example of setting nozzle 365 of print head
Lc in nozzle map 1 with the overwrite protection set.
5
>>
SET NOZZLE MAP
Lc
2
#1:***/VAR
Press the OK button.
6
>>>Lc:#1
2
***/VAR
g
365
/FIX
, , , ,
Press the Up, Down, Left, Right buttons
to set the nozzle map, nozzle number and
overwrite protection (VAR/FIX), and then
press the OK button.
7
>>
>
Lc:#1
2
365/FIX
g
365/FIX
The setting is complete.
To check the numbers of the nozzles
with nozzle map

The numbers of the nozzles for which nozzle map
has been set are indicated on the nozzle print
pattern printout.

Nozzle numbers with overwrite protection are
identied with the
x
mark.
