Oki IP-6620 - Page 114

114
Maintenance
(Panel display)
AUTO NOZZ MAP ERROR
Lc Lm C Y K M Gy
The lower line shows the color with which the automatic nozzle map error occurs.
The error message is also printed on the result of automatic nozzle map.
(Print result of automatic nozzle map error)
XXX: ERROR 1 MANUALLY CONFIGURE
XXX: ERROR 2 MANUALLY CONFIGURE
* XXX indicates the head color and number (e.g. Lm2, Y4).
* The print result does not show the color for which the error occurred. Nozzle map settings from before the
execution are maintained.
Colors for which no error has occurred are shown in the print result.
Meaning
Detection was not performed correctly.
Items to be checked Corrective measures
Check that the media is not skewed or wrinkled
and that there are no other media transfer
problems.
Install the media again or advance it until there are no wrinkles or dirt.
Some media types are not supported by automatic configuration. In such cases,
use manual configuration.
You may also change the media and use automatic configuration.
Check that the pattern is not dirty or damaged.
Check that there is no problem with the print
head (too many missing dots, etc.).
Perform PH. Recovery.
See Clear missing dots (nozzle clogging) on
page 247.
XXX: ERROR 3 PERFORM CLEANING
* XXX indicates the head color and number (e.g. Lm2, Y4).
* The print result does not show the color for which the error occurred. Nozzle map settings from before the
execution are maintained.
Colors for which no error has occurred are shown in the print result.
Meaning
The total of the number of clogged nozzles and the number of overwrite protected nozzles exceeds the limit of 10.
Items to be checked Corrective measures
Check that the total of the number of clogged
nozzles and the number of overwrite protected
nozzles does not exceed 10.
Perform PH. Recovery.
Remove the settings of unnecessary overwrite protected nozzles.
See < STEP2 > on
pa ge 111.
See Clear missing dots (nozzle clogging) on
page 247.
