Advanced operations

>>>MEDIA EDGE GUARDS

OFF

Press the CANCEL button to exit the MEDIA

EDGE GUARDS menu.

>>MISC SETTINGS

MEDIA EDGE GUARDS

Press the ONLINE button.

PRINTER READY

01: PAPER / 1626mm

Activate the color stripe

PRINTER READY

01: PAPER / 1626mm

Press the MENU button.

INFORMATION

Press the Down button to select EDIT MEDIA

PRESETS.

EDIT MEDIA PRESETS

Press the OK button.

>EDIT MEDIA PRESETS

SELECT PRESET NO.

Press the Down button to select MISC

SETTINGS.

>EDIT MEDIA PRESETS

MISC SETTINGS

Press the OK button.

>>MISC SETTINGS

REMAINING MEDIA

Press the Down button to select COLOR

STRIPE.
