Advanced operations

>>MISC SETTINGS

COLOR STRIPE

Press the OK button.

>>>COLOR STRIPE

OFF

Press the Down button once.

>>>COLOR STRIPE

Press the OK button.

>>>COLOR STRIPE

Press the CANCEL button to exit the COLOR

STRIPE menu.

>>MISC SETTINGS

COLOR STRIPE

Press the ONLINE button.

PRINTER READY

01: PAPER / 1626mm
