1.10
9928491 R04 - 2017-2018 RZR XP Turbo / XP4 Turbo Service Manual
© Copyright Polaris Industries Inc.
ITEM
TORQUE
Pickup Screws 7 ft-lb (10 Nm)
Oxygen Sensor 13 ft-lb (18 Nm)
Power Steering Unit Shield Screws 15 ft-lb (20 Nm)
Power Steering Bracket to Frame Nuts 16 ft-lb (22 Nm)
Power Steering Unit to Mount Bracket 30 ft-lb (41 Nm)
Prop Shaft Support Bearing Fasteners 33 ft-lbs (45 Nm)
Prop Shaft to Transmission Fasteners 22 ft-lb (30 ft-lb)
PVT Inner Cover Fasteners
inner
(see image inEngine Installation), page 3.46 for
sequence
STEP 1: Torque to 37 ft-lb (50 Nm)
STEP 2: Torque to 10 ft-lb (14 Nm)
STEP 3: Loosely install bolts by hand
STEP 4: Torque to 37 ft-lb (50 Nm)
STEP 5: Torque to 50 ft-lb (68 Nm)
STEP 6: Torque to 37 ft-lb (50 Nm)
outer
35 in-lb (3 Nm)
Radiator Bracket
8 ft-lb (11 Nm)
Radius Rod Fasteners (Inner) 50 ft-lb (68 Nm) + 45°
Radius Rod Fasteners (Outer) 50 ft-lbs (68 Nm) + 90°
Seat Frame to Main Frame
T-40
8 ft-lb (11 Nm)
M8
14 ft-lb (19 Nm)
M10
30 ft-lb (41 Nm)
Seat Belt Mounting Fasteners 40 ft-lbs (54 Nm)
Seat Slider Plate Screws
4 ft-lb (5 Nm)
Shift Cable
to shifter
13 ft-lb (18 Nm)
Transmission Bracket
37 ft-lb (50 Nm)
Jam Nut
16 ft-lb (22 Nm)
Shock Guard Screws
14 in-lbs (2 Nm)
Shock (FOX)
Body Cap 100 ft-lb (135 Nm)
Bearing Asm 35 ft-lb (47 Nm)
Bleed Screw
14 in-lb (2 Nm)
Eyelet 50 ft-lb (68 Nm)
Shaft Nut
22 ft-lb (30 Nm)
Shock Mount
front
42 ft-lbs (57 Nm)
rear
70 ft-lbs (95 Nm)
Shock Reservoir Mounting Clamps (rear) 35 in-lb (4 Nm)
Skid Plate Fasteners
8 ft-lbs (11 Nm)
Snorkel Shaft Coupler Jam Nut 140 ft-lb (190 Nm)
Spark Arrestor 8 ft-lb (11 Nm)
Spark Plug 9 ft-lbs (12 Nm)
Speed Sensor Screw 12 ft-lb (16 Nm)
Stabilizer Bar Linkage 42 ft-lbs (57 Nm)
Stabilizer Bar Mounting Clamps
front
20 ft-lb (27 Nm)
rear
30 ft-lb (42 Nm)
Starter Cable Nuts
40 in-lb (5 Nm)
Starter Mounting Bolts 7 ft-lb (10 Nm)
Starter One-Way Clutch Screws 9 ft-lb (12 Nm)
Starter Solenoid
Cable Nuts
35 in-lb (4 Nm)
Mounting Bolts 8 ft-lb (11 Nm)
GENERAL INFORMATION
