Status Information, Error Messages and Troubleshooting
R&S
®
SMB100A
486Operating Manual 1407.0806.32 ─ 21
Error
Code
Error Description Remedy
50 Extern reference out of
range or disconnected
External reference is selected but no
external signal is applied or the signal
is out of range.
●
Check the selected refer-
ence signal source (internal
or external) in the "Setup >
Reference Oscillator" dialog.
●
Change setting to 'internal' if
no appropriate external
source is available.
140 This modulation forces
other modulations off
A modulation has been switched on
which cannot be used at the same
time as an already active modulation.
The previous modulation has been
switched off.
Example: Enabling FM modulation
switches PM modulation off.
180 Adjustment failed Adjustment could not be executed The adjustment data have to be
generated first by an internal or
external adjustment or to be loa-
ded into the device (see Chap-
ter 5.2.3.1, "Internal Adjust-
ments", on page 92.
182 Adjustment data miss-
ing
Adjustment data are missing. The adjustment data have to be
generated first by an internal or
external adjustment or to be loa-
ded into the instrument.
183 Adjustment data inva-
lid
Adjustment data are invalid and must
be restored.
The adjustment data have to be
generated again by an internal or
external adjustment or to be loa-
ded into the instrument.
200 Cannot access hard-
ware
The data transmission to a module
was unsuccessful.
The module is not installed, not
properly installed or missing.
201 Hardware revision out
of date
A later version of certain parts of the
instrument is necessary to execute
the function selected.
The driver does not support the
installed version of a module.
202 Cannot access the
EEPROM
A error occurs when writing or reading
a EEPROM.
The EEPROM might be defect
and has to be replaced.
203 Invalid EEPROM data Reading a EEPROM is possible, how-
ever the data are inconsistent.
204 Driver initialization
failed
Initialization of a driver fails when
booting the instrument firmware.
The driver is not compatible with
the hardware or software config-
uration of the instrument.
241 No current list There is no list selected. To execute
the required operation, a list has to be
selected in the related menu.
If no list is available, a new list
must be created.
242 Unknown list type
specified
The list type selected is not valid for
the required operation.
For instance, the file extension for
waveform list files is *.wv. It is not
possible to enter another file exten-
sion when selecting a list.
Check the selected list type.
Device-Specific Error Messages
