R&S SMB100A User Manual

Getting Started
R&S
®
SMB100A
57Operating Manual 1407.0806.32 ─ 21
One of the following options must be installed.
●
R&S SMB-B101 (up to 1.1 GHz)
●
R&S SMB-B102 (up to 2.2 GHz)
●
R&S SMB-B103 (up to 3.2 GHz)
●
R&S SMB-B106 (up to 6 GHz)
●
R&S SMB-B112 (up to 12,75 GHz)
●
R&S SMB-B112L (up to 12,75 GHz without attenuator)
●
R&S SMB-B120 (up to 20 GHz)
●
R&S SMB-B120L (up to 20 GHz without attenuator)
●
R&S SMB-B131 (up to 31,8 GHz)
●
R&S SMB-B140/-B140N (up to 40 GHz)
●
R&S SMB-B140L (up to 40 GHz without attenuator)
Instruments without step attenuator provide a restricted level range at the RF output.
Refer to the data sheet for detailed information.
You can additionally get the following options for microwave instruments:
●
up to 20 GHz (R&S SMB-B120/-B120L)
– high output power option R&S SMB-B31
– low harmonic filter option R&S SMB-B25
●
up to 40 GHz (R&S SMB-B140/-B140L/-B140N)
– high output power option R&S SMB-B32
– low harmonic filter option R&S SMB-B26
See data sheet for detailed information.
Up-to-date information is available at R&S SMB homepage on the internet http://
www.rohde-schwarz.com/product/smb100a.html.
Mod Gen block
The internal modulation sources are configured in this block. Also, the "LF frequency
sweep" can be activated here.
An internal LF generator is available as the internal source for the analog modulations
AM, FM and PHiM. Available modulation shapes are sine and rectangle.
The internal modulation signals are provided at the LF output at the front of the instru-
ment. The LF output signal and the modulations sources for the analog modulations
AM, FM and PhiM can be selected independently from each other.
A pulse generator provides single and double pulse modulation with selectable pulse
widths and periods. Additionally, an option is available to generate pulse train signals.
The R&S SMB offers three different sweep types (frequency sweep, level sweep and
LF sweep) to be activated alternatively. Each type has 6 modes which differ with
respect to the sweep cycle mode (continuous, individual and step-by-step) and trigger-
ing mode (automatic, internal and external). In the "Mod Gen" block, the LF sweep is
configured. Frequency and level sweep settings are accessed via the "RF" block.
Description of Individual Diagram Blocks
