4. Attach the sponge strip [5] that is supplied with the finisher.
5. Attach the guide plate (removed from the finisher) to the cover interposer.
• Attach the front end [6] of the plate ( x 1).
• Attach the rear end of the plate with the anti-static brush [7] ( x 1).
• Use the two small tapping screws that are supplied, and not the machine screws removed from
the finisher guide plate.
6. Release the lock lever [8] ( x 1).
7. Slowly push the finisher against the side of the machine until the brackets [9] go into the
slots.
• Move the finisher carefully, or you will bend the entrance guide plates.
8. Attach the lock lever [8] ( x 1).
9. Connect the connector [10] to the machine.
1. Installation
106
