Letter What It Means
D Left edge blank margin
SP2101 Print Erase Margin
SP mode Specification
Leading Edge SP2101-001
2.5±2 mm
Trailing Edge SP2101-002
Left edge SP2101-003
2±1.5 mm
Right edge SP2101-004
Registration Buckle Adjustment
When the customer is using special paper, buckle adjustment may be required if paper feed problems
arise.
• If the buckle is too large, this can cause wrinkling, creasing, or jams caused by sheets overtaking the
sheets ahead of them in the paper path.
• If the buckle is too small, this can cause jams at the registration roller or skew during paper feed.
1. Enter the SP mode.
2. Open SP1003.
• To prevent wrinkling, creasing, or jams, set a smaller value.
• To prevent jams at the registration roller or to eliminate skew, set a larger value.
SP1003-001 Registration Buckle Adjustment – Tray, LCT
SP1003-002 Registration Buckle Adjustment – Duplex Tray
SP1003-003 Registration Buckle Adjustment – LCT
Adjustment range -9 mm ~ +9 mm (small ~ large buckle)
Initial value 0 mm (Buckle = 10 mm)
Print Image Adjustment
