1. After selecting the test pattern as described above, press to display "5. Mode".
<Engine>
5. Mode
2. Push [#Enter].
SP5024
mm/inch Display
3. Push once.
SP5990>>
Print Mode
4. Push [#Enter].
SP5990-001
All Data List
5. Push to select "Diagnostic Report".
SP5990-005
Diagnostic Repo
6. Push [#Enter].
Diagnostic Repo
execute?
7. Push [#Enter] to print the pattern.
Diagnostic Repor
Processing…
8. You can repeat this procedure for as many test prints as you need.
• After you enter a Print Test Pattern number, the test pattern prints, not the SMC Report. The
machine will remain in this mode until you leave the Service Mode, or switch the printer off and
on.
• After leaving the re-entering the Service Mode, or after turning the machine power off and on,
the SMC Report feature is restored to normal operation.
These patterns can be selected for SP2902-003
5. Service Tables
304
