Feed Station Allowed Size
Tandem Tray (Tray 1) A4 LEF, LT LEF
1. Open the front cover.
2. Completely pull out the tandem feed tray [1] so that the right tandem tray [2] separates
from the left tandem tray.
3. Remove the right tandem inner cover [3].
4. Re-position the side fences [4] ( x 2). The outer slot position is used when loading A4 size
paper.
5. Re-install the right tandem inner cover [3].
