Displays the total number of copy jams.
Display range: 0000~9999
7504 [Jam Location] Paper Jam Location
Displays the list of possible locations where a jam could have occurred. Press the appropriate
key to display the jam count for that location. These jams are caused by the failure of a sensor
to activate.
Paper Late
(Remains ON)
Paper Lag
(Remains OFF)
What It Means
1 At power on
3 Tray 1:ON 53 Tray 1:OFF 1st Paper Feed SN
4 Tray 2:ON 54 Tray 2:OFF 2nd Paper Feed SN
5 Tray 3:ON 55 Tray 3:OFF 3rd Paper Feed SN
6 Tray 4:ON 56 Tray 4:OFF 4th Paper Feed SN (Japan Only)
7 LCT:ON 57 LCT:OFF LCT Paper Feed SN
8 Registration 1:ON 58 Registration 1:OFF 1st Vertical Transport SN
9 Registration 2:ON 59 Registration 2:OFF 2nd Vertical Transport SN
10 Registration 3:ON 60 Registration 3:OFF 3rd Vertical Transport SN
11 Registration 4:ON 61 Registration 4:OFF 4th Vertical Transport SN (Japan Only)
12 Middle Sensor:ON 62 Middle Sensor:OFF Relay SN
13 Registration:ON 63 Registration:OFF Registration SN
14 Fusing:ON Fusing Exit SN
15 Duplex Exit:ON Exit Unit Entrance SN
16 Duplex Exit:ON 66 Duplex Exit:OFF Paper Exit SN
19 Ent Duplex:ON 69 Ent Duplex:OFF Duplex Entrance SN
20 Ent Duplex 1:ON Duplex Transport SN 1
21 Ent Duplex 2:ON 71 Ent Duplex 2:OFF Duplex Transport SN 2
