Paper Late
(Remains ON)
Paper Lag
(Remains OFF)
What It Means
22 Ent Duplex 3:ON 72 Ent Duplex 3:OFF Duplex Transport SN 3
23 Exit Duplex:ON 73 Exit Duplex:OFF Duplex Inverter SN
24 1-Bin Tray:ON 74 1-Bin Tray:OFF 1-Bin Tray SN Japan Only
7504 3000-Sheet Finisher B700 (Corner Stapling, Booklet Stapling)
Finisher 121 Finisher Entrance Sensor
When the paper fails to activate the entrance sensor at the precise time or remains at the
entrance sensor for longer than the prescribed time.
Finisher 122 Proof Tray Exit
When the paper fails to activate the proof tray exit sensor at the precise time after acti-
vating the entrance sensor or remains at the proof tray exit sensor for longer than the
prescribed time.
Finisher 123 Finisher Exit
When the paper fails to activate the exit sensor at the precise time after activating the
entrance sensor or remains at the exit sensor for longer than the prescribed time.
Finisher 124 Staple Tray
When the paper fails to activate the staple entrance sensor at the precise time after
activating the entrance sensor or remains at the staple entrance sensor for longer than
the prescribed time.
Finisher 125 Jogging Tray
When the paper from jogger unit fails to activate the exit sensor at the precise time or
remains at the exit sensor for longer than the prescribed time.
Finisher 126 Corner Stapler
When the stapler unit fails to send any signals while stapling.
Finisher 127 Booklet Stapler
Finisher : When the booklet stapler fails to send any signals during stapling.
Finisher 128 Fold Unit
5. Service Tables
384
