9. Press [#Enter]. Refer to the table on the next page.
Full Exit Tray 2
(7)00001010(0)
1. Paper Feed 1
Bit Description Reading
0 1
7 Rear Side Fence Close Sensor Activated Deactivated
6 Rear Side Fence Open Sensor Activated Deactivated
5 Front Side Fence Close Sensor Activated Deactivated
4 Front Side Fence Open Sensor Activated Deactivated
3 Near End Sensor (see tables below)
2 Paper Height 1 Sensor
1 Paper Height 2 Sensor
0 Paper Height 3 Sensor
2. Paper Feed 2
Bit Description
Reading
0 0
7 2nd Paper Size Switch
See Paper Size Tables Below
6 2nd Paper Size Switch
5 2nd Paper Size Switch
4 2nd Paper Size Switch
3 2nd Paper Size Switch
2 Not used
1 Not used
0 Not used
Input/Output Check
407
