1500 sheets 1000 sheets 400 sheets 70 sheets
bit-3 0 0 0 0 0 0 1 1
bit-2 0 0 0 1 1 1 1 0
bit-1 0 0 1 1 1 0 0 0
bit-0 0 1 1 0 0 0 0 0
3. Paper Feed 3
Bit Description
Reading
0 0
7 3rd Paper Size Switch
See Paper Size Tables Below.
6 3rd Paper Size Switch
5 3rd Paper Size Switch
4 3rd Paper Size Switch
3 3rd Paper Size Switch
2 Not used
1 Not used
0 Not used
Universal Tray Size Detection – N.A. models only
Paper Size Switch Setting (LOW = pressed) Panel Display
11" x 17" LOW HIGH HIGH HIGH HIGH 11" x 17" SEF
81/2" x 14" LOW LOW HIGH HIGH HIGH 81/2" x 14" SEF
81/2" x 11" HIGH LOW LOW HIGH HIGH 81/2" x 11" SEF
11" x 8 ½" LOW HIGH LOW LOW HIGH 81/2" x 11" LEF
51/2" x 81/2" LOW LOW HIGH LOW LOW 51/2" x 81/2" SEF
81/2" x 51/2" LOW LOW LOW HIGH LOW 81/2" x 51/2" LEF
8" x 101/2" LOW LOW LOW LOW HIGH 8" x 101/2" SEF
5. Service Tables
