Machine Level
1. Set a stand ¶ at each corner of the machine.
2. Place a level on top of the machine (front to back). Use a wrench to turn each nut · to level
the machine to less than 5 mm.
3. Check the machine operation. With the customer, determine the best place to attach the
cleaning reminder decal.
4. Place 2 leveling stoppers ¸ under the paper bank frame. Place one under the 8 mm hole
and the other under the 8 x 10 mm hole.
5. While pressing the level stopper flat against the paper bank frame, use a wrench to turn
each nut ¹ to raise the machine.
6. Repeat Step 5 until the long part of the leveling stopper is tight against the underside of the
paper bank frame.
7. After adjustment is completed, turn nuts ¹ to raise them slightly as far as the bottom tray
frame to lock the stoppers in place.
8. Confirm that the machine does not move when you push it left and right.
• If the machine moves, repeat the leveling procedure.
1. Installation
40
