Paper Near-End And Paper End – Trays 2, 3
The machine detects paper near end by counting the number of pulses the motor makes when lifting the
bottom plate.
The paper end sensor [A] receives light reflected from the paper below [B] until the last sheet has been fed.
Then, paper end is detected.
Paper Size Detection
Tandem Tray (Tray 1)
The tandem tray does not have paper size detection switches. Every time the paper size is changed by
moving the front and back fences, you must enter the selected paper size using SP5959-001.
6. Details
488
