SC544 Fusing lamp overheat error 1 (hardware)
SC545 Fusing lamp overheat error 2
• To release the machine after one of these SC codes is issued, just enter the SP mode.
Paper Exit
Fusing/exit motor [A] > timing belt [B] > exit roller [C] via gears and timing belts.
The de-curler rollers [D] remove curl from the paper before it exits. This improves feed through the duplex
unit and finishers.
Image Fusing and Paper Exit
509
