A4 LEF, 8½" x 11" LEF
Paper Weight
2-Hole (NA) 52 g/m
2
~ 163 g/m
2
(14 ~ 43 lb)
3-Hole (NA) 52 g/m
2
~ 163 g/m
2
(14 ~ 43 lb)
4-Hole ( EUR/A) 52 g/m
2
~ 128 g/m
2
(14 ~ 34 lb)
Punch Waste Hopper Capacity
2-Hole (NA) 10K
3-Hole (NA) 15K
4-Hole ( EUR/A) 15K
Operation Modes All (Shift, Proof, Staple)
DIP SW Settings
The correct DIP SW settings of the Punch Unit 531 are provided in the table below for your reference only.
The DIP switches of these punch units do not need to be changed at installation, or adjusted for operation.
Punch Unit Unit No.
DIP SW Settings
1 2 3 4
2/3-Hole (NA) B531-17 1 0 1 0
2/4-Hole ( EUR/A) B531-27 1 0 0 1
0: OFF, 1: ON
Punch Unit (A812)
The Punch Unit A812 is installed in the 3000 Sheet Finisher B706.
Punch Hole Positions
2-hole, 3-hole (NA)
4-hole (EUR/A)
4-hole (North Europe)
Punch Paper Size
2-Hole
A5 ~ A3 SEF, 11" x 17" ~ 8½" x 11" SEF
A5 ~ A4 LEF, 8½" x 11" LEF
7. Specifications
