3-Hole (NA)
A3 SEF, B4 SEF, 11" x 17" SEF
A4 LEF, B5 LEF, 8½" x 11" LEF
4-Hole ( EUR/A)
A3 SEF, 11" x 17" SEF
A4 LEF, 11" x 17" LEF
4-Hole (North Europe)
B5 ~ A3 SEF, 8½" x 11" ~ 11" x 17" SEF
A5 ~ A4 LEF, 8½" x 11" LEF, 5 ½" x 8½" LEF
Paper Weight
2-Hole, 3-Hole (NA) 52 g/m
2
~ 163 g/m
2
(14 ~ 43 lb)
4-Hole (Europe/North Europe) 52 g/m
2
~ 128 g/m
2
(14 ~ 34 lb)
Punch Waste Hopper Capacity
2-Hole 40K
3-Hole (NA) 15K
4-Hole ( EUR/A) 15K
4-Hole (North Europe) 15K
Power Supply DC 24 V (From Finisher)
Power Consumption 60 W
Weight Less than 2.4 K (5.3 lb.)
Operation Modes All (Shift, Proof, Staple)
DIP SW Settings
The correct DIP SW settings of the Punch Unit A812 are provided in the table below for your reference
only. The DIP switches of these punch units do not need to be changed at installation, or adjusted for
operation.
Punch Unit Unit No.
DIP SW Settings
1 2 3 4
2-Hole ( EUR/A) A812-40/A812-67 0 0 0 0
3-Hole (NA) A812-57 1 0 0 0
4-Hole ( EUR/A) A812-30 0 1 0 0
Peripheral Devices (Options)
531
