1. Push the LCT on its stand against the side of the machine.
2. Connect the harness¶.
3. Align the holes ·,¸, ¹ on the side of the LCT with the docking pins on the side of the machine
[B].
• Confirm that the guide pins are inserted correctly into the holes. If the pins do not align with their
holes properly, use a wrench to adjust the positions of the casters [C].
4. Slowly push the LCT onto the pins.
• Confirm that the harness ¶ is not pinched between the machine and the LCT.
• The release button [A] is used to unlock the LCT so it can be disconnected from the machine.
5. Connect the plug º of the LCT power cord to the side of the machine.
6. Attach the clamp [D] and close it around the cable of the harness ¶.
7. Switch the machine on and [#Enter] SP5959 005 (Paper Size – Tray 4 (LCT)) to select the
paper size. For details, see SP5959 in section “5. Service Tables.”
LCT (B473)
57
