DISPLAY PANEL MANUAL
15-7
●The sample program of ANGLE JOG
STEP PROGRAM CONTENTS
1 50 04 08 00 00 20 00 00 ANGLE JOG
＊１
2 40 00 00 00 00 00 00 00 BRAKE
3 90 00 00 00 00 00 00 00 END OF CYCLE
＊1 Change the second byte of the step 1 as follows to change the ANGLE JOG to the TIME JOG.
Step1 50 04
08 00 00 20 00 00
↓
Step1 50 02
08 00 00 20 00 00
