5. FASTENING SETTING mode (Type S)
5-10
a. DRIVER model type
The SPINDLE ASSIGNMENT and the type of DRIVER are selected. For special specification of the
SPINDLE ASSEMBLY, select the type “sp” listed at the end.
Table 5.2-8 DRIVER MODEL
b. Rated torque (Only special type)
The rated torque is set.
c. Gear ratio (Only special type)
The gear ratio is set.
d. DRIVER
Model type selection of the DRIVER
DR1 : DRIVER for SDN - MO - 40
DR2 : DRIVER for SDN - MO - 55
DR3 : DRIVER for SDN - MO - 75
DRIVER MODEL CONTENTS
DR1- 005
(On developing)
SDN - DR1 – 005
DR1- 010H
SDN - DR1 - 010H
[SPINDLE TYPE：SDN−SP1−010SH or SDN−SP1−010FH]
DR1- 010 SDN - DR1 - 010
DR1- 025 SDN - DR1 - 025
DR1- 050 SDN - DR1 – 050
DR2- 050 SDN - DR2 - 050
DR2- 100 SDN - DR2 - 100
DR2- 180 SDN - DR2 - 180
DR3- 180 SDN - DR3 - 180
DR3- 320 SDN - DR3 - 320
DR3- 580 SDN - DR3 - 580
DR3- 1000 SDN - DR3 – 1000
DR3- 1800 SDN - DR3 – 1800
NOTE
Be sure to set the proper settings of the gear ratio and the model type of DRIVER.
