DISPLAY PANEL MANUAL
5-21
Setting key CONTENTS
△ The cursor can be moved to upper position.
▽ The cursor can be moved to lower position.
DELETE The selected step will be removed.
INSERT NOP will be inserted to the selected step.
CHANGE It allows the command of the selected step to be changed.
DETAIL It allows the detail settings of the selected step to be changed.
EXEC The settings will be written to the NUTRUNNER.
QUIT ALL new settings will be canceled.
Table 5.3-1 SELECT PROGRAM SETTING keys
NAME
COMMAND
CODES
FUNCTION
NOP 00h
Nothing is done except for progressing the program by
one step.
SOFT START 10h
The revolution of NUTRUNNER is increased (or
decreased) to the set speed.
HIGH SPEED 20h
The high-speed rotation is kept until the seating torque is
detected.
TIGHTEN 30h
The fastening operation is conducted according to the
fastening method and fastening parameter.
BRAKE 40h The NUTRUNNER is stopped by a brake.
JOG 50h The jogging operation is conducted.
INTERLOCK 60h The interlock operation is conducted.
SWITCH
PARAMETER SET
70h The fastening program switches its parameter set No.
SOCKET RELEASE
80h The socket is released from the bolt.
END OF CYCLE 90h
The fastening program is completed and the fastening
result is evaluated.
TIME DELAY A0h It is used to pause the program for a fixed time interval.
JUMP B0h
OK JUMP B1h
NG JUMP B2h
This command evaluates the fastening data and jumps
to designated step if the condition is fulfilled.
Table 5.3-2 SELECT PROGRAM SETTING COMMAND SET
