DISPLAY PANEL MANUAL
5-43
PARAMETER SWITCH CONTENTS
USED The items are enabled.
UNUSED
The items are removed from display list. NG and Trouble judgments
are disabled.
Table 5.4-2 PARAMETER SWITCH and its contents
No. ITEM No. ITEM
1 Torque method 21 Stretch angle NG
2 Torque turn method 22 Slope 3 torque NG
3 Torque tension method 23 Mid.point judgement torque NG
4 Yield method 24 Torque maximum TROUBLE
5 Fixed time torque method 25 Tightening time TROUBLE
6 Jog 26 Tightening angle TROUBLE
7 Torque keep function 27 Current maximum TROUBLE
8 Peak toque NG 28 Tightening current maximum TROUBLE
9 Final torque NG 29 Cycle time TROUBLE
10 Tightening time NG 30 Seating time TROUBLE
11 Tightening angle NG 31 Seating angle TROUBLE
12 Tightening current NG 32 Snug torque TROUBLE
13 Seating time NG 33 Snug time TROUBLE
14 Seating angle NG 34 Snug angle TROUBLE
15 Snug torque NG 35 Slope 1 torque TROUBLE
16 Monitor angle NG 36 Slope 2 torque TROUBLE
17 Slope 1 torque NG 37 Slope 3 torque TROUBLE
18 Slope 2 torque NG 38 Mid.point judgement torque TROUBLE
19 Final slope torque NG 39 RUN DOWN angle TROUBLE
20 Final slope level NG 40 RUN DOWN torque TROUBLE
Table 5.4-3 PARAMETER SWITCH
