SENSTAR OmniTrax - Page 118

Preparation of trenches
Page 118 OmniTrax Product Guide
Figure 84: SC1 sensor cable lead-in overlap
NOT TO SCALE
processor enclosure
lead-in section
SC1 - 20 m (66 ft.)
2 to 3 m (6.5 ft. to 10 ft.)
minimum
8 m (26 ft.)
minimum
* The 30 cm minimum separation between A-side and B-side active cables is critical to system performance.
30 cm* (12 in.)
minimum
ferrite beads
A-side
B-side
