Silver Network point assignments
OmniTrax Product Guide Page 233
Silver Network point assignments
OmniTrax input point mapping
Point Description Point Description
Diagnostic alarms
1 Enclosure tamper 9 2 V 5 / 1 V 2 rail fault
2 Program flash error 10 Battery fault
3 RAM error 11 Input power fail
4 Processor boot fail
Cable faults
5 Option card fail 12 Side A cable supervision
6 8 V rail fault 13 Side B cable supervision
7 3 V 3 rail fault 14 Side A interference (jam)
8 +5 V / - 5 V rail fault 15 Side B interference (jam)
Point Description Point Description
Sensor alarms
1 AUX input 1 (bit 0 alarm, bit 1
supervision)
7 Option card input Opt5 (bit 0 alarm,
bit 1 supervision)
2 AUX input 2 (bit 0 alarm, bit 1
supervision)
8 Option card input Opt6 (bit 0 alarm,
bit 1 supervision)
3 Option card input Opt1 (bit 0 alarm,
bit 1 supervision)
9 Option card input Opt7 (bit 0 alarm,
bit 1 supervision)
4 Option card input Opt2 (bit 0 alarm,
bit 1 supervision)
10 Option card input Opt8 (bit 0 alarm,
bit 1 supervision)
5 Option card input Opt3 (bit 0 alarm,
bit 1 supervision)
11 to 60 Cable zone #n (bit 0 alarm, bit 1
unused)
6 Option card input Opt4 (bit 0 alarm,
bit 1 supervision)
OmniTrax output point mapping (controls)
Point Description Point Description
1 Processor relay 1 7 Option card relay Opt3
2 Processor relay 2 8 Option card relay Opt4
3 Processor relay 3 9 Option card relay Opt5
4 Processor relay 4 10 Option card relay Opt6
5 Option card relay Opt1 11 Option card relay Opt7
6 Option card relay Opt2 12 Option card relay Opt8
