StarNeT 1000 point assignments
Page 234 OmniTrax Product Guide
StarNeT 1000 point assignments
OmniTrax input point mapping
Point Description Point Description
Auxiliary input alarms
0 Aux alarm 1 (processor 1) 5 Aux alarm 6 (input card 4)
1 Aux alarm 2 (processor 2) 6 Aux alarm 7 (input card 5)
2 Aux alarm 3 (input card 1) 7 Aux alarm 8 (input card 6)
3 Aux alarm 4 (input card 2) 8 Aux alarm 9 (input card 7)
4 Aux alarm 5 (input card 3) 9 Aux alarm 10 (input card 8)
Auxiliary input tamper alarms
16 Aux tamper 1 (processor 1) 21 Aux tamper 6 (input card 4)
17 Aux tamper 2 (processor 2) 22 Aux tamper 7 (input card 5)
18 Aux tamper 3 (input card 1) 23 Aux tamper 8 (input card 6)
19 Aux tamper 4 (input card 2) 24 Aux tamper 9 (input card 7)
20 Aux tamper 5 (input card 3) 25 Aux tamper 10 (input card 8)
Point Description Point Description
Diagnostic alarms
14 processor fail (OR of bits 33 to
40)
15 processor warn (OR of bits 41 to
46)
32 enclosure tamper 40 2V5/1V2 rail fault
33 program flash error 41 battery fault
34 RAM error 42 input power fault
35 processor boot fail 43 Side A supervision fault
36 option card fault 44 Side B supervision fault
37 8V rail fault 45 Side A interference fault
38 3V3 rail fault 46 Side B interference fault
39 +5V/-5V rail fault
Point Description
Sensor alarms
51 to 100 Zone 1 to Zone 50 sensor alarms
OmniTrax 0utput point mapping (controls)
Point Description Point Description
0 Aux control 1 (Processor relay 1) 6 Aux control 7 (Output card relay 3)
1 Aux control 2 (Processor relay 2) 7 Aux control 8 (Output card relay 4)
2 Aux control 3 (Processor relay 3) 8 Aux control 9 (Output card relay 5)
3 Aux control 4 (Processor relay 4) 9 Aux control 10 (Output card relay 6)
4 Aux control 5 (Output card relay 1) 10 Aux control 11 (Output card relay 7)
5 Aux control 6 (Output card relay 2) 11 Aux control 12 (Output card relay 8)
