OmniTrax Product Guide Page 235
a System component list
Component Part Number Description
processor and
enclosure
A4EM0101 OmniTrax processor mounted in an aluminum CSA Type 4 (NEMA 4/IP 66
equivalent) enclosure, provides electronic processing for two sensor cable
sets each with up to 400 m (1312 ft.) detecting cable, includes no option
cards
processor card on
mounting plate
A4EM0301 replacement OmniTrax processor on metal backplate
OmniTrax processor auxiliary cards (an NIC is required for each processor using network communications)
Network Interface
Card (multi-mode
fiber optic)
00BA0301 Fiber optic NIC, mounts on processor, supports two multi-mode 62.5/125
fiber optic data paths (4 fibers), mounting hardware included
Network Interface
Card (EIA-422
copper wire)
00BA0302 EIA-422 copper wire NIC, mounts on processor, supports two EIA-422
(4-wire) data lines, mounting hardware included
Network Interface
Card (single mode
fiber optic)
00BA0303 Fiber optic NIC, mounts on processor, supports two single mode fiber optic
data paths (4 fibers), mounting hardware included
Network Interface
Card (EIA-422/
multi- mode F.O.)
00BA0304 Side A EIA-422 copper wire, Side B multi-mode fiber optic, NIC, mounts on
processor, supports one EIA-422 (4-wire) data line and one multi-mode fiber
optic data line, mounting hardware included
Network Interface
Card
(EIA-422/single
mode fiber optic)
00BA0305 Side A EIA-422 copper wire, Side B single mode fiber optic, NIC, mounts on
processor, supports one EIA-422 (4-wire) data line and one single mode
fiber optic data line, mounting hardware included
Relay Output Card 00BA0400 Relay output card, mounts on processor, 8 Form C relay outputs rated 30
VAC/VDC @ 1.0 A max, non-inductive load, mounting hardware included,
maximum one ROC per processor (cannot be used with UIC)
Universal Input
Card
00BA1200 Auxiliary input card, mounts on processor, 8 inputs, mounting hardware
included, maximum one UIC per processor (cannot be used with ROC)
OmniTrax processor enclosures
Enclosure A4MA0101 OmniTrax processor replacement enclosure, aluminum, CSA Type 4
(equivalent to NEMA 4/IP 66), includes all internal interconnecting cables
Telecom style
enclosure
A4MA0200 Telecom style protective enclosure for above ground field mounting of
processor enclosure, includes tamper switch and wiring harness
(A4HA0100), mounting brackets, mounting hardware and ground stakes,
removable, lockable cover (lock not included), light green enamel, 42.5 x
27.3 x 98.4 cm (16 ¾ x 10 ¾ x 38 ¾ in)
