Page 236 OmniTrax Product Guide
Enclosure
mounting clamp
C7SP0500 Enclosure mounting clamp, for post-mounting the 48 VDC network power
supply (P/N A4EM0200) post size 5 to 12 cm (2 to 4 ¾ in.) O.D., (order 2
clamps per power supply)
Mounting bracket
for Perimitrax
telecom enclosure
A4KT0400 Replacement bracket and hardware for installing an OmniTrax processor in
an existing Perimitrax telecom style enclosure
Telecom enclosure
tamper harness
A4HA0100 Wiring harness to connect the telecom enclosure tamper switch to the
OmniTrax processor
OmniTrax power supply options
12 VDC standalone
power supply, no
enclosure
C7EM0503 Standalone single processor DC power supply, 115/230 VAC, 50/60 Hz
input, 12 VDC 80 W output, without enclosure
48 VDC Network
power supply in
weatherproof
enclosure
A4EM0200 Network power supply, 115/230 VAC, 50/60 Hz input, 48 VDC 100 W output,
mounted in a CSA Type 4 (Equivalent to NEMA 4/IP 66) painted aluminum
enclosure 26 x 23 x 13 cm (11 x 9 x 5 in.)
replacement core
for Network power
supply
GP0141 Power supply core for 48 VDC 100 W output, network power supply
12 VDC auxiliary
device power
supply module
00EM0400 Auxiliary device power supply module, 12 VDC @ 150 mA max. regulated
output power, mounts on door inside OmniTrax enclosure, for use with
processors receiving 48 VDC network power
optional 6 VDC
local battery kit
00KT0900 6 VDC rechargeable battery, mounting bracket and hardware, battery
harness and fuse, mounts inside the enclosure on the door
6 VDC battery GE0487 6 VDC 5 Ah (nominal) replacement backup battery for kit 00KT0900
optional extended
run-time battery
00KT0100
E0414
6 Ah gel-cell battery (minimum 4 hours operation)
2.9 Ah gel-cell battery
OmniTrax sensor cable sets/decouplers/terminators
SC1 sensor cable A3FG0201 50 m (164 ft.) SC1 single cable with 20 m (66 ft.) integrated lead-in, 4 TNC
connectors, 10 ferrite beads, heatshrink
SC1 sensor cable A3FG0202 100 m (328 ft.) SC1 single cable with 20 m (66 ft.) integrated lead-in, 4 TNC
connectors, 10 ferrite beads, heatshrink
SC1 sensor cable A3FG0204 150 m (492 ft.) SC1 single cable with 20 m (66 ft.) integrated lead-in, 4 TNC
connectors, 10 ferrite beads, heatshrink
SC1 sensor cable A3FG0211 200 m (656 ft.) SC1 single cable with 20 m (66 ft.) integrated lead-in, 4 TNC
connectors, 10 ferrite beads, heatshrink
SC1 standalone
decoupler kit
A3KT0601 SC1 cable standalone decoupler includes 2 standalone decouplers and
heatshrink, passes data, blocks DC power
SC1 network
decoupler kit
A3KT0701 SC1 cable network decoupler includes 2 network decouplers and
heatshrink, passes data and DC power
SC1 loopback
termination kit
(legacy component)
A4KT0501 SC1 loopback termination kit includes 4 m loopback cable, 2 standalone
decouplers, 2 TNC connectors, 10 ferrite beads and heatshrink, terminates
detection field and enables processor supervision of sensor cable at the end
of an open SC1 perimeter
SC1 terminator kit A4KT1301 SC1 terminator cable assy. terminates detection field and enables sensor
cable supervision (includes power blocking decouplers and heatshrink)
bulkhead connector
dust caps
GT0944-MNC Screw-on dust cap to protect unused cable connectors on processor
enclosure (2 required per cable set)
SC2 sensor cable A3FG0301 50 m (164 ft.) SC2 two cable set with 20 m (66 ft.) integrated lead-in, 4 TNC
connectors, 20 ferrite beads, heatshrink
Component Part Number Description
