Relay output card
Relay ratings/settings
The dry contact relays are form C and are rated for 30 V @ 1 A max.
Figure 164: Relay output card connection details
Note You make OmniTrax I/O wiring connections on removable terminal
blocks. The screw terminals accept wire sizes from 12 to 24 AWG, with
a 6 mm (1/4 in.) strip length. Remove the terminal blocks from the
auxiliary cards before connecting the wiring.
