Cable tests
OmniTrax Product Guide Page 147
Cable set
A cable-set consists of the two sensor cables (a single cable for SC1) connected to one side of a
processor (A-side or B-side, TX and RX). A cable set can be connected to another cable set
through decouplers. At the end of a perimeter, OmniTrax sensor cables are connected to
terminators.
Figure 130: OC2/SC2 end of perimeter cable termination
Figure 131: SC1 end of perimeter cable termination
cable set
standalone
decouplers
terminator
standalone decouplers
terminator
SC1 sensor cable
