Network components
Page 224 OmniTrax Product Guide
Universal Configuration Module
The Universal Configuration Module (UCM) is a Windows-based software application that
performs the configuration and calibration functions for OmniTrax and all other Silver Network
compatible devices. The UCM also provides diagnostic, monitoring and maintenance functions for
each device. The UCM can reside on the same PC as the NM, or can be located on a separate
computer. The UCM connects to the NM using TCP/IP, and through the NM, can communicate
with any device on the Silver Network without interrupting other network functions. It can also
connect directly to each Silver-based device via USB.
Silver Network repeater
The repeater amplifies, reshapes and retimes the data signals on the Silver Network. There are
three variants of the repeater, each is specific to a type of transmission media. The repeater
doubles the maximum separation distance between network devices. The three variants include
EIA-422 copper wire, multi-mode fiber optic cable, and mixed media EIA-422 + multi-mode fiber.
The repeater is housed in an aluminum enclosure and includes removable terminal blocks for
copper wire connections. The fiber optic variants include ST connectors. The device accepts 12 to
48 VDC, consumes 2 W maximum, and includes an intelligent charging circuit for the backup
battery. Indicator LEDs are provided for DC power, battery power, and network communications.
