A-side
OmniTrax SC1 lead-in cables
B-side
NOTE: Form a 2 m (6.5 ft.) service loop
by wrapping the cables once
around the inside of the telecom
enclosure.
Strip and separate approximately
61 cm (2 ft.) of the lead in cables.
Power cable, ground wire and data
cables not shown.
auxiliary sensor/data
cable conduit
earth
ground
sensor cable
conduit
conduit layout
(in concrete foundation)
power cable
conduit
drain
pipe
telecom enclosure
concrete foundation
enclosure
install the 4 protective grommets
