Processor features
Page 172 OmniTrax Product Guide
Item Description Item Description
1 Processor on-board internal coaxial cable
connectors: (TNC-F) TXA, RXA, RXB, TXB
2 enclosure vent
3 enclosure tamper switch (connects to T8)
4 diagnostic LEDs: D6 door open (enclosure door open), D42 UCM active (UCM connected to processor),
D43 network power fail (no input voltage at T4), D44 internal power fail (internal power supply out of
spec.), D48 battery fail (no battery power available), D47 boot fail (problem encountered on startup
routine), D46 memory fail (flash checksum failure on boot), D45 (reserved for future use), D4 ISR
(flashes at polling rate), D3 plot, D2 CF, D1 JAM
5 T2 - USB port (for connecting UCM)
USB com LEDs: D53 RX, D52 TX
6 reset switch (reboot processor)
7 clock battery 8 T4 - back-up battery connector
9 T3 - power input connector (12 to 48 VDC)
(optional output power to auxiliary power
module for processors powered over sensor
cables)
10 sensor cable power fuses
(1.25 A, 250 V, fast blow)
11 enclosure bulkhead connectors, lead-in cable
connections (TNC-F - TXA, RXA, RXB, TXB)
12 enclosure door hinges (X 2)
13 mounting studs for optional 6 VDC local
battery kit (00KT0900-001)
14 auxiliary power supply module mounting
studs (X 4)
15 enclosure door ground connection
(optional auxiliary power supply module
ground connection)
16 cable gland (X 4) cable entry ports for power
cables, earth ground wire, alarm data cables,
self-test/auxiliary device input wiring
17 enclosure ground stud: earth ground,
enclosure door ground, PCB ground
18 mounting studs for processor mounting plate
19 T5 - relay output connector: left to right, fail,
supervision, alarm B, alarm A
(3 pins per relay - NO, COM, NC)
20 PCB ground connection (soldered)
21 relay activity LEDs: D26 - K1, D29 - K2,
D33 - K3, D37 - K4
22 AUX1, AUX2 - auxiliary device/self-test input
connectors
23 lightning protections devices 24 Form C output relays: K1 fail, K2 supervision,
K3 B-side alarm, K4 A-side alarm
25 T1 - connector for removable flash memory
card (factory use only)
26 J1 - expansion header for auxiliary cards
(NIC, ROC, UIC)
27 enclosure mounting holes - 1 cm (3/8 in.) X 4
and 7 mm (1/4 in.) X 4
28 lockable door latch (X 2)
