OmniTrax components
OmniTrax Product Guide Page 23
• A4KT0301 - OC2 short cable repair kit
• equivalent part for SC1 - A3KT0500
• equivalent part for SC2 - A3KT0800
used to repair damaged sensor cables where
the damaged section is less than 48 cm long
• A4KT0302 (not shown) - OC2 long cable
repair kit
used to repair damaged sensor cables where
the damaged section is less than 3 m long
no equivalent part for SC1/SC2
• A4CA0302 - 50 m OC2 non-detecting cable
used for decoupler overlaps, bypasses,
extending lead-in cable length
(also available in lengths of 25 m - A4CA0301
and 100 m - A4CA0303)
• equivalent part for SC1 25 m - A3CA0601,
50 m A3CA0602, 100 m A3CA0603)
• equivalent part for SC2 25 m - A3CA0701,
50 m A3CA0702, 100 m A3CA0703)
• A4KT0100 - spare ferrite beads (50)
used on non-detecting lead-in cable and cable
bypasses to dampen and contain the detection
field
• equivalent part for SC1 - A3KT0300
• equivalent part for SC2 - A3KT0400
• A4KT1000 - lightning arrestor kit for all
sensor cable types; includes 4 arrestors
used to protect the processor from lightning
strikes, transients and power surges conducted
by the sensor cables
• A4KT1001 - lightning arrestor kit for all
sensor cable types; includes 2 arrestors
• 00BA0400 - relay output card
used to increase the processor’s relay output
capacity from 4 to 12; 8 additional outputs for
signaling alarm conditions when used with local
control mode; provides 8 additional outputs for
controlling auxiliary devices when used by a
Silver Network based remote control processor
• 00EM0400 - 12 VDC @ 125 mA (max.)
auxiliary device power supply, mounts on
OmniTrax enclosure door
for use with processors receiving 18 to 48 VDC
power
