Page 4 OmniTrax Product Guide
Using this guide
This guide provides the information necessary to design, install, setup and calibrate an OmniTrax
system. Chapter 1 is an introduction to OmniTrax perimeter security; chapter 2 provides site
planning information; chapter 3 covers enclosure installation details; chapter 4 describes sensor
cable installation, cable fittings, cable splices, cable repair, and cable tests; chapter 5 details
system powering and data communications, and the processor wiring connections; chapter 6
describes system setup and calibration; and chapter 7 covers the Silver Network. The appendices
provide system component ordering information, recommended installation materials, component
specifications, and details about using the UltraLink I/O system in Network Manager mode for
reporting OmniTrax alarm conditions.
Figures
The figures included in this document are for illustration purposes only, and may differ from the
actual equipment.
Abbreviations
The following abbreviations are used throughout this guide:
• I/O - input/output
• I/P - input
• NAR - nuisance alarm rate
• NC - normally closed
• NIC - Network Interface Card
• NIU - Network Interface Unit
• NM - Network Manager
• NO - normally open
• OC2 - OmniTrax
®
dual sensor cables (300 m / 400 m lengths)
• O/P - output
• Pd - probability of detection
• RF - radio-frequency
• ROC - Relay Output Card
•RX - receive
• SC1 - single cable OmniTrax cable set (max. 200 m length cable sets)
• SC2 - dual cable OmniTrax cable set (max. 200 m length cable sets)
•TX - transmit
• UCM - Universal Configuration Module
• UIC - Universal Input Card
Service statement - We ensure that our products are correctly applied to achieve the maximum benefits for the end-user. We
work hand-in-hand with our customers and remain accessible through all stages of a project - from concept to deployment to
long-term support. We provide design assistance, site surveys, installation support, comprehensive documentation, training,
post-installation annual calibration and maintenance visits, electronics and software extended warranty, rapid factory repair
service and on-call/emergency service. Contact Senstar Corporation to inquire about how a package can be customized for
your unique applications.
