SENSTAR OmniTrax - Page 44

Planning the cable path
Page 44 OmniTrax Product Guide
• Secure the foil in place with plastic tie wraps or electrical tape.
Figure 16: Pipe buried parallel to sensor cables
Figure 17: Buried cables with metal shield
(24 in.)
minimum
below the
horizontal plane
of the cables
60 cm
ground
sensor cables
non-metal drain pipe
foil shield
(or metal shield over pipe)
5
5
c
m
metal shield (or foil) over pipe
ground
side view
sensor cable
sensor cables
non-metal drain pipe
non-degrading
foil (or metal shield)
wrapped around
drain pipe
top view
1 m (3.25 ft.)
1 m (3.25 ft.)
5 cm
(2 in.)
minimum
from cables
