Installing a telecom style enclosure

Page 90 OmniTrax Product Guide

Figure 55: Mounting the bracket and OmniTrax enclosure - rear view

bracket mounting hardware

enclosure

mounting

hardware

OmniTrax

enclosure

threaded enclosure

mounting holes

locking tabs

mounting bracket

telecom enclosure

locking

tab slots
