Simplex 4010 User Manual

8-6
The following is an example of a valid Custom Control equation.
FIRE DET 03-01
(Fire Detect state of M1-1 : IDNet Device: M1-1)
OR FIRE DET 03-02
(or the Fire Detect state of M1-2 : IDNet Device: M1-2)
OR FIRE DET 03-03
(or the Fire Detect state of M1-3 : IDNet Device: M1-3)
HOLD ON 01-01 Pri 9, 9
(Hold ON NAC Circuit: SIG 1 at a priority of 9, 9)
Custom Control Equation
Custom Control Example
Input Statement 1
Input Statement 2
Input Statement 3
Output Statement
Input Opcode
Input Operator
Output Opcode
Technical Manuals Online! - http://www.tech-man.com

Simplex 4010 Specifications

General

Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Manufacturer	Simplex
Model	4010
Battery Backup	24 VDC
NAC Outputs	4
Max Detectors	250
Max Modules	250
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	Up to 93% RH, non-condensing
