Table 10-3. Crash Codes
Code Meaning Cause Corrective Action
0 Illegal Crash Code Erroneous call to crash handler. Code not supported by
4010
1 RAM Memory Fail RAM memory failed pattern check or the newly
calculated checksum did not restore correctly.
Replace hardware
2 Hardware Stack
Fail
Not used – erroneous call to crash handler. Code not supported by
4010
3 Bad Message Index Call to get message string with illegal value. Reload application
4 Bad Switch Value Default for switch when illegal value cannot be defaulted. Reload application
5 ROM Memory Fail ROM memory failed its CRC check, either BOOT or
Application.
Reload application
Replace Hardware
6 OS Initialization
Fail
The 4010 Application failed trying to define an OS
object.
Reload application
Replace Hardware
7 Unexpected
Interrupt
An interrupt vector was executed when that interrupt was
not enabled.
Reload application
Replace Hardware
8 Unexpected
Function
The 4010 application called a BOOT function that does
not exist.
Reload application
Replace Hardware
9 Internal RAM Fail The on-chip RAM failed integrity check during startup. Replace hardware
A Keypad Missing The 4010 keypad is missing. Check keypad connections
/ Replace hardware
B CFIG Format
Mismatch
Indicates a mismatch between the EXEC and programmer
software. For example, using a version 1 EXEC with a
version 2 programmer.
Upgrade EXEC and
programmer software to
same revision.
C Invalid SMPL
Opcode
The SMPL interpreter failed trying to execute a corrupt
program.
Reload job. Check
versions of tools and panel
D Invalid Card
Address
A database routine failed trying to access an illegal card
number.
Reload job. Check
versions of tools and panel
E Invalid Point
Number
A database routine failed trying to access an illegal point
number.
Reload job. Check
versions of tools and panel
F I/O Scan Time-Out Not used – erroneous call to crash handler. Code not supported by
4010.
10 Invalid Get Status The application tried to get a type of data that is not
associated with the data point it was intended for. This
can be caused by using the PC programmer to assign a
point type of “unavailable” to a NAC or 24 PT I/O
Reload job. Check
versions of tools and panel
11 Invalid Put Status The application tried to save a type of data that is not
associated with the data point it was intended for.
Reload job. Check
versions of tools and panel
12 Flash Erase Failure The Flash chip erase function returned an error. Replace hardware
13 Flash Write Failure The Flash chip write function returned an error. Replace hardware
14 Empty Mail Event The OS signaled a mail event but had no mail for the
process.
Reload application
15 No Comm.
Memory
The system was unable to allocate a required
communication buffer.
Reduce cards/reload job
