Simplex 4010 User Manual

8-24
[ALL] [FIRE ACK] [23-01]
Figure 8-30
Example: When all points in List 23-01 are in the condition of FIRE
ACK, then execute the output.
DELAY CNST
When using the input condition qualifier DELAY CNST, and the input statement
is true, the output action is delayed for a specified amount of time (in seconds).
Note: The input must be true for the entire delay time specified.
[DELAY CNST] [21-05] [00020]
Figure 8-31
Each output statement is made up of three fields.
[Hold On] [21-02] [9,9]
Figure 8-32
Continued on next page
Custom Control Programming, Continued
Fields 3 & 4 (Continued)
Output Side (THEN)
Action
Specifier for
Field 2
Point
Field
A
Field
A
Field 1
Field B
Field 2
Field B
Field C
Field 3
Field C
SECOND
STAGE FIELDS
SECOND
STAGE FIELDS
OUTPUT
STATEMENT
Two-stage Input
Condition
Specifier
Two-stage Input
Condition
Specifier
Condition
Point
List Point
Specified
Delay Time
Priority
