1-6
4010-9813 Expansion Power Supply
When more than 4A of Notification or AUX power is required, an expansion
power supply may be added. The expansion power supply provides filtered
24VDC, 4A power for Notification and Auxiliary use. The expansion power
supply is mounted to the right of the SFI/O at the bottom of the chassis.
4010-9814 Suppression Kit
The 4010-9814 suppression kit consists of an expansion power supply designed
to provide regulated 24VDC power for suppression circuits and a suppression
system appliqué that is applied to the outside of the FACP. The suppression kit
mounts in the same hardware slot as the expansion power supply.
4010-9820 Battery Meter Module
The 4010-9820 Battery Meter Module provides an indication of the
charge/discharge state of the FACP’s batteries (internal or external). The
module also provides a constant reading of the current and voltage of the
monitored batteries. This module mounts to the right of the city module.
The 4010 has a maximum of two expansion slots available to support the
following cards.
4010-9810 and -9816 DACT Cards. Two versions of the DACT are offered:
4010-9810 Event Reporting DACT - Five categories of status changes are
supported with this card. The Central Station is notified of
Alarm, Trouble, Supervisory or Waterflow status changes. AC
Fail trouble is delayed for 6 to 12 hours before reporting to the
Central Station. In the event of a CPU failure, the card sends a
“CPU Trouble” message to the Central Station.
4010-9816 Per Point Reporting DACT - Specific information is available
about which point in the system experiences a status change.
The report sent to the Central Station includes the specific point
address along with the point status. The DACT supervises the
system CPU via N2 communication. In the event of a CPU
failure, the DACT sends a “CPU Trouble” message to the
Central Station.
Continued on next page
Optional System Modules, Continued
Optional Modules with
Dedicated Hardware Slots
(continued)
Optional Modules for
Expansion Slots
