Unpack the 4010 using the following information:
• Carefully unpack the system and inspect for shipping damage.
• Select a location for the control panel in a clean, dry, vibration-free area
with moderate temperature (see the “Environmental Specifications” section
in Chapter 1).
Before installing the 4010, read the following guidelines:
• Install the FACP in a readily accessible area with sufficient room to easily
install and maintain the control panel.
• Locate the top of the cabinet approximately five feet above the floor with
the door hinge on the left-hand side.
• Count the number of conductors needed for all devices and cut the
appropriate knockouts. Pay careful attention to the routing for Power-
Limited and Non-Power Limited wiring. You must maintain a 1/4-inch
separation between these two types of wiring. All terminal connections
are Power-Limited except those to the AC power, Battery, and City
Circuit, and contacts when switching Non-Power Limited sources.
• Review the precautions and warnings at the front of this publication.
• All wiring must comply with the National and/or Local codes for fire alarm
systems. All wiring must test free of grounds.
• Leave sufficient room for batteries in the bottom of the back box (see the
label inside the 4010 back box for more information).
• Enclosure must be level and plumb when installed.
When installing the 4010, you should be familiar with the following standards:
• NEC Article 300 Wiring Methods
• NEC Article 760 Fire Protective Signaling Systems
• Applicable Local and State Building Codes
• Requirements of the Local Authority Having Jurisdiction (AHJ)
