Simplex 4010 User Manual

6-21
This section describes how to configure a User-Defined Switches and LEDs.
The following assumes that you have chosen User Defined SW/LED as your
option after entering the Configure Points menu.
Use the following steps to configure a User-Defined Switch or LED in the 4010
FACP.
1. Press <MENU>.
2. Press <NEXT> or <PREVIOUS> until [PROGRAMMING] is displayed
and then press <ENTER>. A warning appears, indicating that the 4010 is
no longer in the Fire Alarm Operation mode.
3. Press <ENTER> to continue.
4. Press <NEXT> or <PREVIOUS> until <CONFIGURE POINTS> is
displayed and then press <ENTER>.
5. Press <NEXT> or <PREVIOUS> to scroll through your choices until
<USER DEFINED SW/LED> is displayed and then press <ENTER>.
6. Press <NEXT> or <PREVIOUS> to scroll through the choices listed
below. Once your choice is displayed, press Enter.
- User LED 1
- User LED 2
- User LED 3
- User Defined Key 1
- User Defined Key 2
7. Press <NEXT> or <PREVIOUS> to scroll through your list of choices until
the desired option is displayed and then press Enter. Your choices are
shown in Table 6-9.
Continued on next page
Configuring User-Defined SW/LED
Overview
Configure a User-Defined
Switch or LED
Please Wait . . .
Fire Alarm Operation Suspended
Pro
g
rammin
g
