Simplex 4010 User Manual

6-12
Table 6-4. Digital Pseudo Point Configuration Choices
Function Description
Edit Device Type
(See Note 1)
Changes the Hardware Device Type of the Point
Edit Point Type
(See Notes 2)
Changes the Software Point Type of the Point.
Your choices are:
• Utility Point
• Fire Point
• Trouble Point
• Supervisory
Edit Point Label
(See Note 2)
Changes the 40-Character Label of the Point
Clear Point Label
(See Note 2)
Blanks the 40-Character Label of the Point
Edit Mode
(See Note 1)
Changes the Mode of Operation for the Point
Notes:
1. This function not allowed for Digital Pseudo points.
2. To complete these functions, refer to their appropriate section
in this publication.
This section describes how to configure analog pseudo points A27 through A50.
A1 through A26 are system points and cannot be edited. Use the following
information to configure analog pseudo points in a 4010 FACP.
1. Press <MENU>.
2. Press <NEXT> or <PREVIOUS> until [PROGRAMMING] is displayed
and then press <ENTER>. A warning appears, indicating that the 4010 is
no longer in the Fire Alarm Operation mode.
3. Press <ENTER> to continue.
Continued on next page
Configuring Digital and Analog Pseudo Points, Continued
Configuring Digital Pseudo
Points (continued)
Configuring Analog Pseudo
Points
Please Wait . . .
Fire Alarm Operation Suspended
Technical Manuals Online! - http://www.tech-man.com

Simplex 4010 Specifications

General

Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Manufacturer	Simplex
Model	4010
Battery Backup	24 VDC
NAC Outputs	4
Max Detectors	250
Max Modules	250
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	Up to 93% RH, non-condensing
