Simplex 4010 User Manual

11-12
User control functions, such as Manual Evac, City Disconnect, Control Point
Bypass and Elevator Recall Bypass, are available from the High Level Status
screen by pressing <FUNCTION>. Pressing <FUNCTION> also accesses
operations including latching earth faults, displaying the current time and date
when the system is abnormal, and performing lamp test.
In addition to the pre-defined functions listed above, the 4010 supports two
“User-Defined” function keys. The two user-defined key choices in the function
menu are “User Defined 1” and “User Defined 2.” These user-defined keys may
be programmed to perform often used functions. A 40-character custom label
may be assigned to these user-defined keys.
Use Steps 1 through 3 to access the Function Control menu.
1. From the High-Level Status screen, press <Function>.
2. Press <NEXT> or <PREVIOUS> to scroll through the function options
(see Table 11-3) until the desired option is displayed and then press
<ENTER>.
3. Press <NEXT> or <PREVIOUS> to select ON or OFF for that option and
then press <ENTER>.
Continued on next page
User Control Functions
Overview
Using the Function Options
