B-8
Either an RS232 Card or Modem Card may be added to the 4010 system. Even
though these cards are optional, if an RS232 or Modem card is configured, it
must reside at Card Address 4. There are two hardware points and eight card
status points associated with the both the RS232 card and Modem card.
Both the RS232 Card and the Modem Card have eight card status points
associated with them. The card status points described in this section apply to
either card. The following table describes the card status points for both the
RS232 or Modem card.
Table B-8. Card Status Points for RS232 or Modem Card
Point Label Description
4-CS1 Missing Card This trouble indicates that the card is not communicating with the
master.
4-CS2 Wrong Card This trouble indicates that the card returned a card type as something
other than a RS232 or Modem card type (respectively).
4-CS3 Port A Disconnected If Port A is a supervised port, and disconnected, this point will indicate
this with a trouble.
4-CS4 Port B Disconnected If Port B is a supervised port, and disconnected, this point will indicate
this with a trouble.
4-CS5 Primary Telco This point indicates a trouble in the Primary Telco line (not presently
supported).
4-CS6 Secondary Telco This point indicates a trouble in the Secondary Telco line (not
presently supported).
4-CS7 Port A Ground Fault This point indicates a ground fault trouble on Port A (not presently
supported).
4-CS8 Port B Ground Fault This point indicates a ground fault trouble on Port B (not presently
supported).
The RS232 and Modem cards have two hardware points associated with them.
Both of the RS232/Modem points are user configurable. However, the points
have no labels associated with them, because they cannot be viewed on the front
panel. Table B-9 is a list of the points on the RS232/Modem cards.
Continued on next page
Hardware Points, Continued
RS232/Modem Card
RS232/Modem Card Status
Points
RS232/Modem Points
