B-9
Table B-9. Points on the RS232/Modem Cards
Point Label Description
4-1 None Port A point. Default to unsupervised 80 character
Printer port.
4-2 None Port B point. Default to command line port.
The DACT card is an optional card that may be added to the 4010 system. The
DACT card is mutually exclusive with the Network card, and if configured, must
reside at Card Address 8. There is one hardware point and seven card status
points associated with the DACT card.
The DACT Card has seven card status points associated with it. The following
table describes the card status points for the DACT card.
Table B-10. Card Status Points for SDACT Card
Point Label Description
8-CS1 Missing Card This trouble indicates that the card is not communicating with the
master.
8-CS2 Wrong Card This trouble indicates that the card returned a card type as something
other than an DACT card type.
8-CS3 Central Station This trouble indicates that communication was lost with the Central
Station.
8-CS4 Phone Line 1 This trouble indicates that Phone Line 1 has been disconnected.
8-CS5 Phone Line 2 This trouble indicates that Phone Line 2 has been disconnected.
8-CS6 Program Checksum This trouble indicates that the on board DACT card checksum test has
failed.
8-CS7 DB Version
Mismatch
This trouble indicates that the configuration loaded on the DACT card
differs from the configuration on the master.
The SDACT card has one hardware point associated with it. The point does not
have a label, because it cannot be viewed from the front panel. Table B-11
describes the point on the SDACT card.
Continued on next page
Hardware Points, Continued
RS232/Modem Points
(continued)
DACT Card
DACT Card Status Points
SDACT Points
Hardware/Pseudo Points
